GE IS220PRTDH1B RTD Input Pack for Mark VI Turbine Control
| Place of Origin | US |
|---|---|
| Brand Name | GE |
| Certification | COO |
| Model Number | IS220PRTDH1B |
| Minimum Order Quantity | 1pc |
| Price | $7000 |
| Packaging Details | New and original factory, individual box packing |
| Delivery Time | 5-7days |
| Payment Terms | T/T |
| Supply Ability | 999pcs |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | GE IS220PRTDH1B RTD Input Pack | Product ID | IS220PRTDH1B |
|---|---|---|---|
| Function | Combustion Optimized Inputs | Series | Mark VI |
| Product Net Depth/Length | 330mm | Product Net Height | 200mm |
| Product Net Width | 100mm | Product Net Weight | 2kg |
| Warranty | 1year | ||
| Highlight | GE Mark VI RTD input pack,turbine control RTD module,GE IS220PRTDH1B RTD pack |
||
Product Description
GE IS220PRTDH1B RTD Input Pack
Product Specifications
| Attribute | Value |
|---|---|
| Name | GE IS220PRTDH1B RTD Input Pack |
| Product ID | IS220PRTDH1B |
| Function | Combustion Optimized Inputs |
| Series | Mark VI |
| Dimensions (L x W x H) | 330mm x 100mm x 200mm |
| Weight | 2kg |
| Warranty | 1 year |
Product Description
The GE IS220PRTDH1B is an RTD Input Pack part of the Mark VIe Series, designed for distributed control systems. It serves as an interface between 1-2 Ethernet I/O networks and RTD input terminal boards, integrating a shared processor board and a dedicated RTD acquisition board.
Key Features
- RTD Sensing: Supports 8 three-wire RTD inputs with 10mA multiplexed excitation; compatible with TRTDH1D/H2D boards
- Connectivity & Power: Uses dual RJ45 Ethernet ports for communication, 3-pin power input, and DC-37 pin connector for terminal board links
- Reliability: Processor board runs self-tests and verifies hardware-code matching via board IDs
- Auto-Reconfiguration: Enables seamless I/O pack replacement with automatic firmware download
- Performance: A/D converter samples signals 4x/second or 25x/second; supports RTDs up to 300m from cabinet
This industrial-grade component operates in -30 to 65°C environments and is manufactured in the U.S., making it ideal for critical temperature monitoring applications in turbine control and other industrial processes.
