GE IS200STCIH2A Terminal Board 24-Channel Input Mark VI Series
| Place of Origin | US |
|---|---|
| Brand Name | GE |
| Model Number | IS200STCIH2A |
| Minimum Order Quantity | 1pc |
| Price | $5200 |
| Packaging Details | New and original factory, individual box packing |
| Delivery Time | 5-7days |
| Payment Terms | T/T |
| Supply Ability | 999pcs |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | GE IS200STCIH2A Terminal Board | Product ID | IS200STCIH2A |
|---|---|---|---|
| Series | Mark VI | Function | Terminal Board |
| Product Net Depth/Length | 330mm | Product Net Height | 200mm |
| Product Net Width | 100mm | Product Net Weight | 2kg |
| Warranty | 1year | ||
| Highlight | GE Mark VI terminal board,24-channel input module,turbine control terminal board |
||
Product Description
GE IS200STCIH2A Terminal Board
Product Specifications
| Attribute | Value |
|---|---|
| Name | GE IS200STCIH2A Terminal Board |
| Product ID | IS200STCIH2A |
| Series | Mark VI |
| Function | Terminal Board |
| Dimensions (L x W x H) | 330mm x 100mm x 200mm |
| Weight | 2kg |
| Warranty | 1 year |
Product Overview
The GE IS200STCIH2A is a simplex contact input terminal board from the Mark VI series, designed for industrial automation applications. This robust component supports 24 contact inputs and is compatible with various DC excitation voltages.
Key Features
- 24-channel input: Supports dry contact voltage inputs with compatibility for 18.5-32V DC via pluggable terminal blocks
- Advanced interference protection: Built-in noise suppression and 4ms hardware filtering for reliable operation in electrically noisy environments
- Flexible installation: Compatible with DIN rail mounting or cabinet bolt fixing for versatile deployment
- Robust communication: Interfaces with PAIC I/O modules using D-type connectors and Ethernet connectivity
- Comprehensive protection: Features excitation voltage loss detection, contact response verification, and 0.5A self-recovery fuse protection
Technical Details
This terminal board features a sophisticated design with over 80 resistors, capacitors, diodes, and 1 integrated circuit. The input current is precisely regulated (2.5mA for first 21 channels, 10mA for last 3 channels) with hardware filtering (4ms) for stable operation. The wiring uses #18 AWG wire with separate grounding for the shielding layer.
Installation & Compatibility
The IS200STCIH2A supports both DIN rail and flat surface mounting using included metal brackets. It comes equipped with 52-terminal pluggable terminal blocks for easy wiring. This terminal board is designed exclusively for simplex systems and maintains signal conditioning consistent with TBCI standards.
