GE IS200CABPG1BAA Control Assembly Backplane

GE  IS200CABPG1BAA Control Assembly Backplane

Product Details:

The IS200CABPG1BAA, developed by General Electric, is a pivotal Control Assembly Backplane (CABP) within the Innovation Series, a component subseries of the Mark VI Turbine Control System.

This system represents a significant advancement over the Mark V series, expanding its applicability from gas and steam turbines to wind turbines, thus embracing  energy environments. As one of the final GE Mark product series to utilize the patented Speedtronic control system technology, the Mark VI series remains a sought-after solution in the market.

the IS200CABPG1BAA combines modular flexibility, safety-centric design, and technical precision to deliver a reliable foundation for advanced turbine control, embodying GE’s commitment to innovation and performance in industrial automation.

Features:

1.Modular Design: The backplane features five slots for plugging in various PCBs (e.g., BAIA, DSPX, ACL_, BIC_, BPI_/FOSA boards), enabling seamless interaction and external signal interfacing. Each slot is uniquely assigned to specific board types, ensuring organized system integration.

2.Safety Mechanisms:Keyed Connectors: Prevents misalignment or incorrect insertion of boards, safeguarding against damage.

3.Spatial Separation: Physically distinct connectors and spatial layouts eliminate the risk of accidental cross-connections.

4.Voltage Segregation: Utilizes separate multi-conductor cables for low-voltage (<50V) and high-voltage (>50V) applications, ensuring safe operation.

5.Jumper Configuration: 21 jumpers (J1-J12 for external interfaces, J13-J21 for card slots) allow customization for specific applications, with detailed configurations referenced in GEI-100268A.

6.Terminal Board Placement: Strategically positioned near cable entry points for user I/O, optimizing accessibility and system organization.

​
