GE Mark VI IS200BICIH1ACA Bridge Interface Controller Board GE Turbine Control

GE Mark VI IS200BICIH1ACA Bridge Interface Controller Board GE Turbine Control

Product Details:

The IS200BICIH1ACA  unit was manufactured and designed by General Electric and made to be a part of the GE Mark VI series.

The IS200BICIH1ADB is an interface card designed and manufactured by GE Industrial Systems for its Innovation Series, intended to be installed in an Innovation Series board rack. It features an artwork revision of "B," with a backwards-compatible functional revision "D" and a non-backwards-compatible functional revision "A." Available for global shipment, it comes with an extensive 3-year warranty.

Features:

Interfaces and Connections: Supports the I/O Interface and Operator Interface of the GE Innovation Series Turbine Control System. The front panel features three key connectors for drive functionality: PFBK1, PFBK2, and PSRC. Nineteen daughterboards (11 AOCA and 8 DVAA) are soldered onto the board.

Daughterboard Functions: AOCA daughterboards provide eight independent comparator circuits for comparing input voltage signals. DVAA daughterboards draw power and clock sources from the interface card, offering two VCO circuits and a pulse-train voltage-compatible output.
